PROGrid High Load Capacity Molded Grating

Bedford’s PROGrid High Load Capacity (HLC) molded FRP grating is high-strength, corrosion-resistant and low-maintenance — just like our PROGrid molded grating products. Plus, it’s engineered to carry higher loads than steel grating and other traditional types. Our molded HLC grating is available in 4′ x 6′ panels with 1 1/2″ and 2″ thicknesses and comes in GPFR, IFR and VFR resin systems in standard gray.

Check Inventory Quote Now

Available Colors:

Gray

Home
/
Our Products
/
PROSeries
/
PROGrid Molded Grating
/
PROGrid High Load Capacity Molded Grating

Expand to Learn More

Available Resin Systems

PROGrid HLC molded grating is available in three resin systems, each providing different levels of corrosion protection. All three resin systems meet Class 1 Flame Spread Rating per ASTM E-84 test standards.

GPFR: A general-purpose orthophthalic polyester resin system that offers good corrosion resistance at an economical price.

IFR: A premium-grade isophthalic polyester resin system that provides excellent corrosion protection.

VFR: A vinylester resin system that provides the highest level of corrosion protection.

NOTE: Load carrying bars are oriented to run in the 6′ dimension of the panel. Panels furnished with closed bars on all sides.

Graphic showing dimensions of 4' by 6' finished structural fiberglass panel size.

Applications

Flooring, platforms and ramps
Storage areas
Assembly lines
Long-span walkways
Trench covers with vehicular traffic

Features

High strength
Corrosion resistant
Low conductivity
Fire retardant
Low maintenance

Allowable Spans for Vehicular Loads

Allowable Spans for Vehicular Loads	Wheel Load (lb) (½ Axle Load + 30% impact)	Load Distribution		Allowable Span in Inches
Allowable Spans for Vehicular Loads	Wheel Load (lb) (½ Axle Load + 30% impact)	Parallel to Axle¹	Perpendicular to Axle¹	1.5″ Deep HLC Molded Grating	2″ Deep HLC Molded Grating
AASHTO Standard Truck⁴32,000 lb Axle Load – Dual Wheels (*formerly AASHTO H-20)	20,800	20″ + 4″	8″	1′-2″	1′-5″
Automobile Traffic 5,000 lb Vehicle – 1,500 lb Load 55% Drive Axle Load	2,220	8″ + 4″	8″	2′-2″	2′-8″
5 Ton Capacity Forklift 14,400 lb Vehicle – 24,400 lb Total Load 85% Drive Axle Load	13,480	11″ + 4″	11″	1’1″	1′-5″
3 Ton Capacity Forklift 9,800 lb Vehicle – 15,800 lb Total Load 85% Drive Axle Load	8,730	7″ + 4″	7″	1’0″	1′-4″
1 Ton Capacity Forklift 4,200 lb Vehicle – 6,200 lb Total Load 85% Drive Axle Load	3,425	4″ + 4″	4″	1’7″	2′-1″

NOTES: Allowable Spans for Vehicular Loads

Load is carried by the grating load bars immediately under wheel + four additional load bars adjacent to wheel.
Allowable Span is based on a 0.25″ maximum deflection and a Factor of Safety of 3.0. Other criteria may be required by certain construction codes. Check code requirements to determine design criteria.
ALLOWABLE SPAN IS STRONGLY DEPENDENT ON WHEEL WIDTH AND VEHICLE WEIGHT/LOAD CAPACITY. If your application varies from the values given on this table, contact Bedford for application assistance.
Load based on the AASHTO Standard Truck Load as defined in AASHTO LRFD Bridge Design Specifications, 2nd Ed. This does not imply that the allowable span meets the deflection requirements of this specification.

Browse PROGrid High Load Capacity Molded Grating

Image of grey 1 1/2 X 1 X 2 inch high load capacity FRP molded grating.

High Load Capacity Molded Grating – 1 1/2″ x 1″ x 2″ HLC

Image of grey 2 X 1 X 2 inch high load capacity FRP molded grating.

High Load Capacity Molded Grating – 2″ x 1″ x 2″ HLC

Chemical Resistance Guide

Get detailed tables on chemical compatibility based on resin manufacturers’ data, including maximum allowable concentrations and temperatures.

Download Guide
